Revolutionary Double-switch Design
A incorporated electronic switch alongside another removable switch effectively assists
the XR10 stock Spec avoid some flaws of ordinary or one-switch ESCs. The interior switch
makes the wiring convenient, the outside switch is in fact handy whenever automobile shell is
create on along with the integral switch isn't any considerably longer touchable.
Special Design for INVENTORY Class Racing
Reliable equipment alongside great software (contains 5 typical ready-to-use
pages) produces a fantastic energy treatment plan for the STOCK span of 1/10 scale touring automobile,
buggy battle.
Programming/Upgrading/
information learning Wirelessly
With Hobbywing's "WiFi Express" module and iPhone or an Android os phone (using the HOBBYWING
WiFi Link software applications make), the customer can from another location system parameters, update firmware and
check appropriate information of ESC without making the control stand.
Minimal Size & Light Weight
This ESC is smaller and lighter versus standard variation XR10
expert therefore's the mini kind of XR10 specialist 160A. The little size
(31.5x25.6x16.1mm) makes the installation convenient in addition to the
light-weight (simply 28g w/o cables) provides more excess weight margin
whenever adjusting the total amount the framework.
Super Internal BEC
The integral switch mode BEC with a maximum output
of 6A and voltage adjustable between 6V and 7.4V
enables the consumer to utilize different high voltage servos.
Adjustable Throttle & Brake PWM Frequencies
Independent and adjustable throttle & brake PWM frequencies guarantee accurate and accurate
throttle and braking system control for a lot of classes of tournaments (esp. the stock system).
Data-logging Capability
This ESC features the data-logging function that might record
the utmost ESC & motor conditions, the minimal battery power
voltage, many engine RPM and an such like. immediately and
allows users to test those information via a LCD system industry or
WiFi module after every use.
Item Specification
Type
- Scale : 1/10th
- Brushed/Brushless : BL
- Sensored/Sensorless : SD
- Waterproof : No
Specifications
- Cont./Peak Present : 80A/380A
- Input Voltage : 2S Lipo/5-7 Cell NiMH
- BEC production : change Mode: 6V/7.4V,3A
Wires & Connectors
- Input Wires : Black-14AWG-200mm*2
- Output cables : Black-14AWG-200mm*3
- Input Connectors : No
- Output Connectors : No
Fan
- Size : 20x20x8mm
- Voltage amount : 5-7.4V
- Powered by : BEC
ESC Programing via
- SET Button on ESC : perhaps not Supported
- LED Program Box : not Supported
- LCD Program Box : Supported
- WiFi Module : Supported
- Program Port : specific system Port
Firmware
- Firmware Upgrade : Supported
Size & Weight
- Size : 31.5x25.6x16.1mm
- Weight : 54.5g (w/Wires)
Applications
- Motors : SL BL Motors
SD BL Motors - Vehicles : STOCK amount of 1/10th Touring car & Buggy Racing
- KV Rating/T Count : 1/10th Touring Cars≥10.5T, 1/10thBuggy≥13.5T
