The current MINI-Z is initiated receiver, servo and ESC by 1 managed PCB product. Although unique MR-03EVO Chassis Set has split receiver as 1 item. By purchasing and starting an optional receiver product before utilized transmitter, permits Kyosho (EX-6R/KT-531P), KO Propo (EX-2/EX-RR), Futaba (T7PX/T7XC/T4PM), and Flysky (Noble NB4) transmitters. Further, by setting up groundbreaking Central Processing unit which control servo function simply, it improves interior feedback of positioning control that will effortlessly be 11.2 times faster than present VE professional models. The newly developed control system understands the most truly effective ever steering feeling into the MINI-Z history. The ESC besides improves the effect rate in maximum 100 times faster than present VE expert models. The included KYOSHO SPEED ABODE XSPEED 85 (8500KV) brushless engine features a one-piece aluminum instance marketing efficient temperature dissipation for superior cooling. Unlike past framework sets, you should alter towards brushed motor mode through I.C.S manager to set up an optional brushed engine. The I.C.S manager additionally allows more accurate environment alterations become made. Groundbreaking advanced performance features within the MR-03EVO just take the MINI-Z competition experience to a different location degree! The SP edition has nickel plated hex screws and an oil surprise (MZW432) as standard. Additionally, the ball diff is especially finished with red anodizing. In addition, groundbreaking top fingers with different caster views (1 degree/2 degree/3 level) are included allowing wider environment range. The Red Limited variation newly features red artificial elements through chassis being well coodinated utilising the red anodized engine and ball diff.
＊First MINI-Z MR-03 Chassis Set that adopts split ESC and receiver design.
＊Includes brand new KYOSHO SPEED HOME XSPEED 85 brushless engine (8500KV).
＊I.C.S manager features step by step steering and throttle parameter modification, and switching between brushless and brushed modes.
＊Powered by separate CPUs for ESC and receiver, increased inside processing cost leads to precision steering and throttle control.
＊Equipped with ball bearings and red anodized Ball Diff Set II.
＊Newly designed separate receiver target and front top supply mount render tread modification easier.
＊Compatible with MINI-Z Racer MR-03EVO SP Chassis Set Red Limited (W-MM 8500KV) the MR-03 framework.
＊Including newly developed front top arms with caster views (1 level, 2 degree and 3 level)
＊Special variation designed with a colored framework, which just avialable inside framework set.
In line with the MR-03VE specialist framework, newly produced split receiver target and front top supply mount make tread modification easier.
Receiver products available are for KYOSHO, KO and FUTABA transmitters and also will be attached/detached by reducing receiver target through the top framework.
New KYOSHO SPEED RESIDENCE XSPEED 85 brushless engine (8500KV) features a one-piece aluminum example that knows efficient heat dissipation.
Packed with Ball Diff Set II that decreases fat of aluminum elements about the spur gear component and optimizes safety regarding hub component. This will be a must-have product and it's used frequently in competition-level race.
Complete ball bearing specs minmise drive loss
TECHNICAL INFORMATION
- Length 123.5mm
- Width 70~76mm
- Height 35mm
- Wheelbase 94.0mm(LL)
- Tread F:61.5~63.0mm/R:61.5~63.0mm
- Motor Mount MM
- Tires F: 25x8.5mm (provided individually)/R: 25x8.511mm (offered separately)
- Gear Ratio 7.36.35.54.9:1
- Weight 135g (approx.)
- Motor KYOSHO SPEED ABODE / XSPEED 85 (8500KV)
KIT CONTENT
- MR-03EVO-W-MM Factory assembled framework with KYOSHO SPEED HOUSE XSPEED 85 8500KV brushless motor
- Parts set for changing front component tread
- 6T7T8T9T Pinion gears
- Wheel wrench
- Tools for pinion gears
- Spare wheel peanuts
REQUIREMENT DOING
- Receiver unit
- Transmitter suitable for receiver unit
- Auto Scale Collection (body set, tires, tires)
- AAA x 4 alkaline batteries or Ni-MH batteries for chassis
- Batteries for transmitter
