Tamiya 58489 - 1/10 RC High Performance 4WD Off Road Racer Avante 2011  [58489]

In March 1988, Tamiya circulated an electrical R/C 4WD rushing buggy called the "Avante" and possesses now since become a genuine device in Tamiya's R/C history. This product showcased a unique shaft-driven 4WD system which was extracted from Tamiya's initial 4WD R/C buggy, the Hotshot. It showcased an exceptionally high level design including a FRP double-deck framework design, longitudinal engine & battery pack roles, and a formula-type human body with framework fairing. It was prepared with revolutionary elements such as a tight gearbox with 3 little planetary gears, a center diff to enhance security, an entirely adjustable suspension, and cam-lock wheel caps.

The Avante ended up being a unique R/C device which showcased a cutting-edge design. After two decades, many of the Avante's mechanisms are receiving to be standard features on contemporary R/C vehicles. The very best pure battle buggy comes home in 2011.

Tamiya has provided the Avante (2011) the initial re-release therapy exactly like other re-released buggies as an example the Buggy Champ and Hotshot. Here is an easy introduction from improved points.

• Principal framework product is changed from FRP to carbon fiber. Original FRP upper/lower decks appear to have been replaced with 2.0mm thick carbon fibre decks to greatly help increase framework power and rigidity. Chassis design is optimized for creating modern R/C gear.
• Carbon Fiber Rear Damper keep back damper stay is thicker versus original and its particular material in addition is changed to carbon fiber. Kept and right remains are linked to further enhance rigidity.
• Assembly Universal Shafts WO universal shafts can be utilized for both front and backside to reduce friction loss.
• Better Damper repair The gold-colored oil damper cylinders feature base caps for easier maintenance particularly changing o-rings.
• Durable Polycarbonate Body Shell our body, wing, and framework fairing had been constructed with polycarbonate for superb off road durability.
• Wheel Axle/Clamp Type Wheel Hubs Wheel axles happen changed to standard pin-secured kind. And aluminum wheel hubs, secure wheel accessory can be done. The hex wheel hubs assist accessory of off road tires like Item 53880 big Dish tires (4WD/Front, 62/25) and Item 53881 big Dish Tires (straight back, 62/35) plus the initial cam-lock type tires.
• Duralumin front knuckles initial die-cast front side knuckles are changed with duralumin knuckles to help enhance durability and power. Amazing knuckles work comparable shape although the original.Compatible with a comprehensive choice of electric batteries packages. The Avante (2011) works with numerous Tamiya battery pack things such as Ni-Cd, high-capacity Ni-MH, and lightweight LF battery pack packages.
• Latest R/C techniques The Avante works alongside Tamiya R/C systems like the 2.4GHz systems.
• The initial Packaging are Revived! The package with this particular re-release model comes due to the identical design and dimensions even though initial Avante. Additionally, similar to the original Avante, most of the components are kept in blister packages.
• The "Avante" logo and right back wing sticker it's still just like the original. Other stickers will be of another Tamiya design.

Specs:



• Length: 420mm
• Width: 240mm
• Height: 115mm
• Wheelbase: 260mm
• Tread (L/R): 200mm
• Minimum Ground Clearance: 40mm
• Weight: 1300g
• Double-Deck Frame
• Tires (F/R): 38/88mm
• Polycarbonate Body
• F/R Multi-Link Suspension
• F/R Metal Oil Dampers
• Gear Ratio: 1:8.33

Features:



• Mini resin bumper.
• front part double wishbone suspension system system.
• Radius supply protector.
• front part stabilizer.
• front side strut towerbar for improved rigitity.
• Front C.V.A. oil damper with tapered coils springtime.
• Pin increase tire.
• Internal sponge.
• Cam-loc wheel.
• Steering tie rod.
• Universal joint.
• Front gearbox features compact planetary differential w/ metal pinion gear.
• Carbon top deck, part of the double-deck framework layout.
• Metal propeller shaft.
• Steering servo (not included).
• Polycarbonate undertray.
• Longitudaly-mounted motor.
• Receiver (perhaps not included).
• ESC (included).
• Back gearbox top access hatch.
• Back steel C.V.A. damper unit.
• Rear strut tower.
• Back double wishbone suspension system system.
• Back stabilizer.
• Adjustable wing mount.
• Polycarbonate human body.
