XRAY 370012 X12 2020 US Specs  [XR-370012]

XRAY X12

2019 All-new Specs

• All-new EU and United States Edition both created & optimized for specific traction conditions
• All-new EU Edition is optimized for low-, medium-, and high-traction conditions
• All-new Usa Edition is optimized for high- and very-high traction conditions
• All-new 2.5mm graphite framework for EU Edition with battery pack backstop grooves
• All-new 2.0mm Swiss 7075 T6 aluminum chassis with battery pack backstop grooves
• All-new right back wheelbase adjustment
• All-new top clamps with composite bushing for better durability
• All-new bulkheads use unique top clamps
• All-new graphite back brace with integrated backstop and O-ring battery power mount system
• All-new O-ring for securing the battery
• All-new adjustable graphite battery power backstop with 4 positions
• All-new considerable front side part graphite bumper owner

General

• XRAY 1/12 pan-car with authentic 100percent self-developed XRAY components, produced and manufactured by XRAY in Europe
• Legendary XRAY premium design, workmanship & material quality and unmatched concentrate on the absolute most dependable details
• Simple yet effective and proven design, well thought-out details, unmatched precision of small details
• High-competition design with consider ultra-low fat, causing super-lightweight construction
• Optimized for interior carpet rushing additionally outside asphalt rushing

Chassis

• EU Edition featuring CNC-machined framework from rigid custom-manufactured 2.5mm high-grade graphite product with specially-designed element for carpeting and asphalt racing
• US Edition featuring CNC-machined framework from premium 2.0mm Swiss 7075 T6 aluminum material
• Chassis & right back pod function pre-drilled centerline holes for optimum fat security modification utilizing HUDY Balancing Tool #107880
• Chassis includes holes and grooves for composite battery power backstops
• Body articles with fully-adjustable body holders; optional super-fine +1 or +2mm human anatomy backstops created for even better body height adjustment
• Chassis design allows either horizontal or straight electric batteries placement
• Chassis design allows to change right battery pack placement
• Chassis design enables to change one of many tips wheelbase

Front suspension system system:

• High-competition, fully-adjustable front suspension system system with super-clean design of the many composite suspension system system system parts
• EU Edition featuring front paid off & upper hands and steering obstructs made out of hard product to help make the car easier to drive and supply smoother steering
• US Edition features unique graphite suspension system arms that decreases torsional flex of hands in to the corners of very-high traction tracks, making the auto more reactive and better to drive
• Shims included for adjusting top supply position
• Precision steering block and front top ball bones to possess additional accurate steering
• Bumpsteer shims for enhanced steering
• Lower suspension system system hands function smart eccentric aluminum inserts for fast & easy track-width adjustment
• Optional aluminum 0.5mm and 1.0mm eccentrics for developing track width
• Ride height modification shims for fast, accurate, and hassle-free trip height modification for various track conditions. Pair of 0.2, 0.4, and 0.6mm ride height modification shims are included.
• fast & easy front side component caster modification via included clips
• All composite elements manufactured by XRAY making use of premium self-developed composite mixtures which guarantee perfect flex in regards to the suspension system elements yet difficult adequate to withstand hefty crashes
• Reactive caster modification (preset 2.5°, 5.0° or 7.5°) via easy-to-change eccentric bushings
• Ultra-precise wheel axles CNC-machined from premium HUDY Spring Steel™ in addition hardened and hand ground for precision fitment
• High-precision, HUDY Spring Steel™ top pivot balls ensure super-fine movement of front component suspension
• Composite reduced pivot balls for smooth front suspension system movement
• Lightweight front top 3mm adjustable HUDY Spring Steel™ camber turnbuckles can withstand hefty crashes
• Quick & effortless wheelbase modification by going the entire front part part part suspension system system system on framework 2mm front or back

Steering:

• Unique adjustable servo mount can accommodate all types of 1/12 servos, and allows modification of servo to chassis centerline
• Floating servo doesn't touch framework, eliminating undesired tweak
• Super-tiny yet robust steering obstructs with specially-designed axles prevent axle spinning while tightening the wheel locknuts
• Pivoting front suspension system has super-smooth hardened steel kingpins supported by soft springs. Optional medium, hard, and extra-hard suspension system springs available.
• Tiny yet robust servo saver with effortless Ackermann modification via included shims
• 4-spring servo saver for exact, smooth steering
• Specially-designed narrow composite ball joints
• Adjustable, super-lightweight Swiss 7075 T6 aluminum turnbuckles

Right Back pod:

• Compact, ultra-lightweight slim back pod consist of high-strength aluminum bulkheads, graphite brace, and strong high-grade 2.5mm graphite plates
• Unique aluminum bulkheads and top bulkhead clamp are CNC-machined from premium extra-hard Swiss 7075 T6 aluminum, additionally black coated for extended life & fashionable look
• Optional eccentric top clamps enables to change back wheelbase
• Light, little pod pivot ball decreases the surplus fat of going elements and increases the movement selection of the trunk pod plate
• Optimized right back pod url positions
• Rear pod top dinner includes mounting space for optional part surprise (for different damping faculties)
• Premium-grade graphite top deck provides solid attachment for shock absorber to rear pod
• Premium graphite a great way link brace holds the inside tubes plus part springs and body posts
• Premium graphite a proven way hyperlink brace enables to put together graphite adjustable battery backstop and features grooves the O-ring which secures the battery
• Super-easy motor top access
• Rear pod accommodates all motors
• Ride height shims for ultra-fine back journey height adjustment
• Rear differential features high-grade precision carbide balls (for spur gear), hardened and precision-ground steel D- shims, and premium carbide 3x8mm axial thrustbearing
• Ultra-lightweight graphite straight back axle
• Precision-molded spur gear made from XRAY's exclusive composite product, ensuring genuine operating, super-quiet procedure, super lightness and robustness for managing effective motors
• Aluminum straight back hubs machined from lightweight aircraft aluminum, specifically lightened and black-coated for fashionable look
• Lightweight backside wheel mounting screws for reduced rotating weight
• Aluminum straight back left wheel hub with center-balanced clamping mounting system, guarantees protected mounting while eliminating vibration and run-out
• Easy right back track-width modification via included shims
• Rear body articles are installed towards the framework via an extensive independently-mounted graphite owner, ensuring human body downforce is precisely based in the chassis
• Rear pod fat stability could be merely modified via shims between engine and bulkhead
• Straight part springs have more constant and smoother compression for better out-of part making and paid back traction rolling

Shock:

• XRAY micro surprise with comparable design to its “big brother” counterpart in XRAY’s effective T4 touring automobile platform
• Centralized surprise absorber position
• 4 frontward, 4 rearward surprise place choices
• Fully-adjustable shock with hard-anodized aluminum shock human body for superior durability, and of course black-coated for trendy look
• Fine-threaded shock human body for fast & easy surprise springtime preload adjustment
• Tiny, thin shock membrane provides super-smooth damping characteristics
• Super-soft silicone shock O-ring for smooth procedure, and improved sealing
• Ultra-finely completed shock shaft with precise-molded composite surprise piston guarantees optimal oil motion and smooth shock absorber action
• Simple yet smart shock construction permits fast & effortless shock-length modification for downstop
• Shock spot modification via shimming of mounting ball studs
• Rear pod component security managed by component pipelines which give equalized lateral damping both in directions while eliminating unwanted rebound
• Rigid centrally-mounted shock mount stops tweak, and notably improves lateral stability
• 1-hole piston for enhanced damping characteristics
• Shock size adaptor is roofed to boost shock size

Assembly & help:

• Highest quality composite parts guarantee super-precise fitment, effortless construction, and smooth procedure of parts
• Premium 3D full-color Instruction Manual
• Exclusive Virtual Online Setup Sheet database with and endless range of set-up sheets for battle tracks through the entire world
• Premium, unmatched XRAY online support

Modification opportunities:

• Front camber, caster, and toe
• Front & backside wheelbase
• Front & straight back track-width
• Front, center, and back journey height
• Front springs
• Central surprise absorber size & position
• Downstops
• Pod damping
• Bumpsteer
• Weight balance
• Ackermann
• Front brace stiffness
• Differential setting
• Servo spot
• Battery place
