Axial SCX10 Aftermarket Pendulum Wheel Weight 21mm Hex SCX023X by GPM  [SCX023X]

Pendulum axle weight tuned for SCX10 crawling

This pendulum wheel axle weight is designed to place mass low at each wheel to steady the vehicle during slow speed crawling. The brass pendulum narrows at the top and flares at the bottom to keep weight low, while the bearing and Delrin collar let the mass swing smoothly through different steering and suspension positions.

Installation and fit notes: mount the pendulum and 21mm hex on the outer drive portal to retain a low chassis centre of gravity, note the 21mm hex increases wheel offset by 16mm compared with the original, and one pendulum assembly weighs 136 grams. Wheels need a 45mm inner diameter and a 5mm wheel thread hole for fitting.

Package contents include the installation hardware: 21mm hex adapter (2 pcs), stainless steel pin 2x10 (2 pcs), 5mm spring steel shims (2 pcs), 5mm metal washers (2 pcs), 19mm stainless steel hex socket screws (2 pcs), and a central bearing with Delrin collar.

Fit this pendulum weight when you want a lower centre of gravity and better wheel bite on technical terrain; double-check wheel bore and thread size before ordering.
