Serpent SER903020 Serpent Viper 990 4wd 1/8 GP  [SER903020]

Serpent SER903020 Serpent Viper 990 4wd 1/8 GP
Price:
NZD$1,165.70
Brand:
Serpent
Model:
SER903020
Please kindly input your name and email address, we will inform you once we have the restocking.
Or you may find similar product under the
R/C Models - On-Road - Touring Cars - Nitro Powered category
Write a review
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
alt="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP" title="Serpent SER903020 Serpent Viper 990 4wd 1/8 GP"
  • The ultra-narrow framework is milled because of enable paid off radio meal including improved flex. keeps the enhanced flex traits. The important thing opening inside the tank is narrower, due to the narrower chassis.
  • The main fat connection is established from underneath and enables a sudden modification of the fat.
    the extra fat it self is fixed using a nylock nut. Bulletproof!

  • the leading fat connection became besides mounted through base permitting comfortable access on weight.
  • Also the key fat is obviously adjustable through bottom.
  • There are 2 additional locations to put a little fat, simply behind the servo-saver.
  • And at motor.
  • The engine is lowered 1mm for improved flex and also to reduce the CG
  • The right back from framework has a slot. This will be explained a short while later here. It's related to adjustable flex. Besides holds 2 steel countersunk screws that behave as a counterpart of down-stop screws. It can benefit to keep the down-stop more accurate and consistent
  • Talking about flex: we tested a huge amount and another the improvements descends from reducing radio stations dish by 2.5mm. We also changed the form of it.
  • The front part of the automobile could be modified to more flex by eliminating leading stiffener bracket
  • The back with this specific vehicle are often adjustable concerning the flex. To regular buttocks features the verified, one-piece rearplate
  • As an option it is usually feasible to utilize a softer buttocks utilizing a optional 2-piece rearplate
  • The radio-box is totally brand-new. The “backbone” from this is a carbon dish and an aluminium framework.
    The aluminium servo mounts are eccentric and certainly will be installed in 2 ways to adjust them towards model of servos.
    The receiver package is more roomy in comparison with one present our 988, nonetheless it's exceedingly compact. It offers room enough additionally for older sort receivers together with transponder

  • This new industry is set up towards radio dinner in a flexible way to have the ability to maybe not influence the flex of car.
    The expanding method of getting frame keeps the atmosphere industry inside desired spot without impacting flex.

  • The end is quite new.
  • It features a brand new design to allow an re-active toe-change and prevent any binding anyhow!
  • By changing the positioning with this particular hyperlink the total amount of toe-gain under compression might be modified. The placement shown could be the “neutral” destination.
  • Since the top of url is changed by a suspension supply, we furthermore changed the top pivot inside upright. It truly is now fairly simple to alter the most effective camber.
  • The height by using this pivot ball is adjustable by changing the aluminium insert. You will find 3 positions
  • The upright holds an aluminium insert where in actuality the ball bearings of this wheel axle remain. In that way we are capable attain an ideal roundness also under load to ultimately achieve the minimal friction for this transmission feasible.
  • In in this way additionally it is quite simple to eradicate the wheel axle/driveshaft for maintenance
  • The front part steering-block features the very same construction.
  • The aluminium insert supplies the same benefits like in straight back with improved drivetrain effectiveness and enhanced easy maintenance
  • But because this insert is eccentric, because could be possible to change the roll-centre and las using a trailing or leading set-up.
    Obviously the steering-blocks stay left/right symmetrical and certainly will be utilized with option1 also option2 levers.
  • The front part top suspension system bracket now has a greater design that delivers a better placement to prevent camber or caster problems using bushings.
  • The unique lighter 2-speed shaft is 10g (!) lighter and features a super-true mounting of 18t pulley adapter.
  • 7075 T6 Aluminium 5mm framework meal
    The 5mm aluminium framework has perfect symmetrical kind furthermore for flex and fat circulation. The ultra-narrow chassis is extremely light, though it 's still however strong in critical places.

  • The cable sort front side anti-roll club is ball raced. It's a simple task to change and adjust due to the available front part part end design. The standard cable is 2.5mm and 2 optional thicknesses can be had. The pivot ball url system directs the suspension motion on club and enables effortless tweak modification.
    The steering obstructs are with this arms with springtime steel 8.5mm pivot balls, which operate really smooth and well protected in nylon cups, and generally are simple to adjust with a 2.5 hex device.

  • The long durable front part paid down wishbones could be the open-style hands just like the 977. An aluminium surprise mount meal is screwed concerning the paid down wishbone. This allows the shock attachment explain be placed further outwards increasing shock movement. Leading reduced arms are put up towards the most effective brackets with nylon holders. The kit includes 2 variants: in and out. This method also permits quick and easy front drive shaft upkeep.
    Absolutely the 988 shut hands are usable as well

  • The staying and right interchangeable upper arms are set up with 3 spot nylon suspension system pin inserts. The 3 location inserts enable camber-change corrections and are usually frequently in addition held arranged by the anodized aluminium top brackets. Under the top brackets, spacers enables you to alter their angle or height. Caster is modified with clips towards the most notable pivot pins. Equivalent videos may applied to the paid down pivot pins to improve wheelbase.
  • The black anodized aluminium front side axle has Japan made one-way bearings. Spring metal drive cups affix to the long and slim spring-steel drive shafts with CVD system. The ball raced spring steel wheel axles have actually really aluminium quick-change levers. The available front side part end design allows without headaches removal of one of the keys axle and driveline parts.
  • The primary mounted seervosaver enables simple and easy quick Ackermann modification. The servosaver features a high installed insert which is present in 3 functions. Another 2 Ackermann functions can be obtained towards steering obstructs.
  • The end construction with aluminium brackets is a tremendously available design, that permits for effortless maintenance and cleansing. Dis-assembly demands getting rid of a few screws. Changing a belt if needed, is a facile task. The eccentric bearing holders on straight back shaft allow modification of belt anxiety. Your entire buttocks is expunged together unit through framework by eradication of a few screws.
  • The cable type backside anti-roll club is ball raced. It's installed towards the back bearing obstructs and it's also quite simple to alter and adjust. The conventional cable is 2.5mm and 2 optional thicknesses could be had. The pivot ball hyperlink system directs the suspension system motion towards club and allows simple tweak adjustment.
  • The slim solid back axle in Serpent spring metal has a lightweight 9mm wide 48T pulley. Spring steel, CVD sort, drive shafts link the trunk shaft to spring steel wheel-axles with aluminium quick-change levers. A very durable and resilient drivetrain.
  • The back floating body mount which is connected to the up-rights with 2 hands is concentrated by a carbon-fibre and steel guider. The mount has 4 functions for each part available, dedicated to body shell utilized and traction available. The threaded holes in regards to the end of the human anatomy mount supply you with the option to add further body-supports.
  • Optionals
    A considerable variety of optional elements is must even more improve performance, price, fat and seems.
    www.serpent.com/903020

    Communications
    - website
    - Promo webpage
    - Facebook web site
    - Viper 990 Twitter person group
    - YouTube video’s
    - Online set-up sheets
    - the help of companies, dealers and team motorists around the world

    Merchandising
    a pleasing choice of tops, sweaters, coats, caps, bags, tools and decals.

    Design
    Serpent Viper 990 . Created by Michael Salven.
    With great the help of all team-drivers and 989/988 drivers!
