XRAY 360006 - Xray XB4'19 - 4WD 1/10 Electric Off-road Car  [XR-360006]

XRAY XB4’19

2018 All-new:

• Recent EOS Champion, European Champion, United States Of America Champion and World Champion platform
• Redesigned framework accommodates brand-new paid off engine mount to decrease the CG
• Lower motor mounts decrease the fat host to engine and main slipper clutch/diff, increasing cornering cost and stability
• Redesigned reduced composite core bulkhead fits the modern paid off aluminum motor mount
• Redesigned component guard permits engine be put lower
• Improved surprise absorber reduced shims provide more accurate surprise shaft movement
• Improved construction and manufacturing properly both front side & right back differential crown gears leads to quieter procedure and increased dependability

General:

• Designed for most useful performance anyhow degrees of racing
• Engineered with understanding of smallest details
• Manufactured with popular imaginative craftsmanship from premium European materials
• EFRA, ROAR, FEMCA spec compliant for stock and modified racing
• Super a facile task to build, arranged, keep, and drive
• Developed, developed and styled by Dipl. Eng. Juraj Hudy, produced solely by XRAY in Countries In Europe on earth's many higher level RC manufacturing facility
• Revolutionary off road platform with brand new standard for premium quality, reliability and performance
• Premium XRAY solution & support

Chassis:

• Smarter framework fat balancing options assist the engine mount and center diff create to have frontwards or backwards
• Unique XRAY Multi-FlexTM technology for effortless framework flex adjustment
• Swiss 7075 T6 hardcoated 2.0mm aluminum framework with countersunk holes for flush, smooth underside
• Tough composite component guards completely fit the framework to seal against dust and protect from component impacts
• Compact electronics dish permits mounting the rate controller for fast & simple decrease and assembly
• Graphite front side, top & right back top decks separate from framework flex modification and work just within the front part, primary, and rear diff assemblies
• Composite & graphite framework braces for fine-tuning from the framework flex
• Independent servo mount allows the steering servo become setup towards framework without pressing it, ensuring removing undesired framework tweak and enhancement of general traction
• Two various electric batteries straps fast -or- very long included. The long battery power strap enables battery become setup either frontwards or rearwards
• Battery foam right back spacer guarantees the battery power wont autumn out
• Thick 3.5mm graphite front shock tower & 3.0mm right back shock tower with numerous shock mounting and roll center positions
• Extra robust front part side component & backside bulkheads permit utilising the differentials just using 4 screws

Differentials & Drivetrain:

• Front & backside gear differentials with adjustable oil viscosity, featuring 35T top steel gears and 14T metal pinion gears
• Molded front & straight back gear differentials for super-smooth, maintenance-free procedure, features long-lifespan HUDY Spring Steel™ outdrives

• Innovative aluminum motor mount permits frontwards or rearwards motor destination for fat security adjustment
• Motor eccentric mounting meal inserts into a motor holder/drivetrain assistance, enabling fast & easy engine rotation for gear mesh and safeguarded clamping with one screw

• Robust main slip-adjustable clutch with 81T main spur gear molded from exclusive key combination of composite material
• Internal 1:2.5 drive ratio
• 3-pad slipper clutch with ultra-efficient SLS product to get additional efficient & precise slide modification, and HUDY Spring Steel™ hardened outdrives for extra lifespan and reliability
• Constant velocity drives (CVD) are constructed of special HUDY Spring steel for repaid fat and increased durability. The shafts are hand ground for maximum precision
• Safety collars for several CVD drive shafts to hold mounting pins securely in place
• Ultra-lightweight 12mm wheel hex drive hubs CNC-machined from Swiss 7075 T6 keeping in mind black-coated have actually really ultra-true hex clamping design which guarantees solid mounting of wheel
• Optional 14mm offset wheel hex drive hubs intended for super-fine track-width modification: -0.75mm, 0mm, +0.75mm and 12mm optional wheel hex drive hubs: -0.75mm, +0.75mm, +1.5mm, +2.25mm, +3.00mm, +3.75mm, +4.5mm
• Full set of 22 high-speed, blue-sealed ball-bearings used through drivetrain to be sure optimum effectiveness, degreased and oiled with Aero Shell® Fluid 12 for maximum smoothness and endurance

Suspension:

• Swiss 7075 T6 aluminum suspension system system holders front and rear
• Integrated Suspension system system Settings (I.S.S.) for fast & easy suspension system system geometry developing utilizing eccentric bushings placed into aluminum suspension system system holders
• Specially-designed suspension system system system elements created from cautiously developed personalized composite mixtures to make sure appropriate flex and durability
• Race-perfected suspension system geometry for superior performance and freedom in lots of battle conditions.
• Lightweight 1-piece caster obstructs with preset 9° caster with easy adjustable roll center spot featuring larger areas for simple and quick disassembly of CVDs; optional 6° & 12° caster obstructs available
• Front framework function pre-angled caster of 8° with the adjustable I.S.S. settings a combination 16~20° of total caster are achieved
• Tiny yet robust steering obstructs molded from a specific composite combination for optimum power featuring adjustable paid down roll center.
• Very compact 0° toe-in back uprights work 3 various top roll center jobs, staggered inner/outer bearing sizes for improved load assistance and unsprung weight, and wheelbase adjustability via included shims
• Oversized exterior bearings in uprights to for increased effective loads
• HUDY Spring SteelTM product for turnbuckles (featuring a tougher core) works extremely well for front side & rear upright linkages, steering system, and servo saver
• Anti-roll pubs constructed from special springtime steel product to assist the car at both front part and back are setup toward diff situations & might be just modified via linkages; laser-engraved markings for effortless recognition, easily obtainable in various sizes for fine-tuning

Steering:

• Simple, effective dual-arm steering system with essential adjustable servo saver guarantees perfect steering and simple Ackermann and bump steer modification

Shocks:

• Consistent, dependable membrane-free big-bore shocks with bleed-screw surprise cap design function up-stop shock pole travel modification (via O-rings) and downstop modification (via shims under pistons)
• Swiss 7075 T6 aluminum shock systems, paid off nut & bleeder surprise caps are difficult coated
• Super-precise molded Delrin™ pistons can be had with 2-hole design & opening diameters 1.6mm and 1.7mm for accurate surprise modification; for personalized modification, a few blank pistons (no holes) are included
• Shock rods are machined from a specific metal product, accuracy hand-ground for maximum smooth procedure as well as hardened for increased lifetime
• Shock springs are faster allowing more fine journey height modification; manually determined, plumped for and matched into pairs to make sure equal size and damping faculties; laser etched for effortless recognition. Two forms of springtime sets are within the kit.
• Full distinct linear -or- progressive surprise springs available
• Premium silicone natural oils laboratory tested and calibrated to be sure highest possible perseverance and quality

Bumper, Body, Wheels:

• Strong composite straight back wing holder
• Front paid down bumper protrudes from base with this framework to absorb all impacts from contact associated with the framework in addition to the track surface
• Beefy 6mm dense human body articles from unique composite material for optimum strength
• High-downforce XB4 human anatomy is superior, low-profile, and aerodynamic to totally fit the XB4 design, with front display and top roof movement systems for appropriate venting, and side downforce areas and top primary rib for greater stability
• Specially produced 12mm hex hub tires for high-competition competition; featuring reinforcement ribs to remove deformation and molded from multipurpose item to retain kind despite results

Assembly, Set-up & Assist:

• Premium 3D full-color Tips & supplementary sheets
• To grasp the set-up possibilities we recommend the famous HUDY Set-up Book that is laden up with over 40 pages of top-quality images and easy-to-read RC automobile set-up explanations
• Exclusive Virtual On Line Setup Sheet database with countless set-up sheets for competition songs through the entire world
• Premium, unmatched XRAY online help

Modification Possibilities:

• Fully-adjustable front side component and rear suspension system system geometry: caster, camber, toe, kick-up, anti-squat, ride height, downstops, track-width, roll center, wheelbase, roll facilities, Multi-Flex™
• Adjustable front part & rear gear differential action (via oil viscosity)
• Adjustable slipper clutch
• Adjustable HUDY Sprint Steel™ turnbuckles (steering, front & right back top links)
• several upper & reduced surprise mounting areas at front component & rear
• Adjustable Ackermann and bumpsteer
• Adjustable front part & back anti-roll bars
• Chassis pre-drilled holes for fat balance modification
