XRAY 370703 X1 2018 Specs [XR-370703]

Price:

NZD$662.62

Brand:

XRAY

Model:

XR-370703

Not Available

Please kindly input your name and email address, we will inform you once we have the restocking.

Or you may find similar product under the
R/C Models - On-Road - Formula Cars category

Write a review

alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"

Description

Dimensions

Class: 1/10 formula
Width: Adjustable 180mm front component, 185mm right back (depends on tires used)
Lenght: 410 mm
Wheelbase: 264 mm
Weight: 375 g
Ready-to-run fat: 985 g (varies determined by equipment used)

Chassis

Chassis: 2.5 mm carbon fiber, CNC machined
Body: XRAY X1 1/10 formula sort

Drivetrain

Type: 2WD direct drive to rear axle
Rear Axle: metal shaft with ball differential
Primary: Spur/pinion
Bearings: High-speed ball-bearings (13)

Suspension

Front: Spring-supported, kingpin-style front side component suspension system system with composite steering obstructs and graphite upper & paid down suspension system system arms
back: traditional back pod, adjustable via pivot-ball links, managed by component tubes
Rear Shock: Central adjustable oil-filled shock absorber

Geometry

Ride Height: Adjustable front + rear
Camber: Adjustable front
Front Caster: 312° adjustable caster
Track-width: Adjustable front + rear
Toe: Adjustable front
Downstop: adjustable front part + rear
Anti-roll club: 1.2 mm front
Ackermann: adjustable with servo saver supply and steering block
Steering: Direct linkage between steering supply and steering obstructs
Balance: Front/rear weight stability adjustable via battery pack destination

Other

Wheels: perhaps not included
Tires: Not included
guidelines: complete colour instruction manual
Packaging: Carton industry with synthetic bags with parts
Additionally included: Lexan Formula human body & front side wing, HUDY Diff Grease, Authentication Certificate, elements list & exploded view, shock oil
Not included: Radio system (transmitter and receiver), steering servo, engine, pinion gear, battery power, rate controller, charger, tires, tires, inserts, high-strength fibre tape, double-sided tape, CA glue, bearing oil, tools
