Xray NT1 - 2018 Specs - 1/10 Luxury Nitro TC  [XR-330014]

Dimensions

• Class: 1/10 nitro touring car
• Length w/o human anatomy: 381 mm
• Chassis size: 341 mm
• Wheelbase: 258~260 mm
• Width: adjustable 197~200 mm
• Weight: 945 g
• Ready-to-run fat: 1630 g

Chassis

• Chassis: CNC-machined 3.0 mm Swiss 7075 T6 aluminum
• Shock towers: machined laminated carbon graphite (front component 2.5 mm + back 3.5 mm) with numerous shock mounting and camber url roll center positions
• Radio tray: machined laminated carbon graphite 2.5 mm

Drivetrain

• Type: triple gear, 4WD
• Final drive ratio (FDR): 2-speed: initial 7.56; 2nd 5.27 (at 1:1 overdrive)
• Front differential: sealed, silicone-filled gear diff
• Rear differential: sealed, silicone-filled gear diff
• Drive axle: front CVD drive shafts - Hudy Spring metal™ right back dogbone drive shafts - Hudy Spring Steel™
• Suspension: pivot ball suspension system system
• Shocks: machined aluminum, oil-filled, coil-over shocks reduced for improved suspension system travel
• Pinion gear (std): hardcoated aluminum 1st: 16T ; 2nd: 21T
• Spur gear (std): molded composite first: 59T ; 2nd: 54T
• Arms: standard
• Adjustability
• Ride height: adjustable front part + rear
• Camber: adjustable front + rear
• Caster: adjustable front
• Toe: adjustable front part + rear
• Downstops: adjustable front part + rear
• Roll center: adjustable front side + rear
• Ackermann: adjustable front
• Front anti-roll pubs: without choice - adjustable blade design or cable design 2.0 mm
• Rear anti-roll club: cable design 2.0 mm
• Equipment
• tires: perhaps not included
• guidelines: full-color guidelines with 3D images
• Set-up guide: 2-color Set-Up Book (39 pages) – not included, available for get a hold of just additionally set-up sheet
• Packaging: carton field with synthetic bags with parts
• Additionally included: Authentication Certificate, elements list & exploded view, decals
• Not included: radio system (transmitter and receiver), individual transponder, steering & throttle servos, motor, manifold & exhaust, novice field & novice package battery, receiver battery pack, glowplug igniter, battery power charger, 1/10-scale bodyshell (200 mm), tires & tires, Lexan® paint, model R/C automobile fuel (nitromethane), tape, ac filter & oil, CA glue, bearing oil, medium-grade (blue) threadlock, tire truer, tools
